Stihl TS480i Petrol Disc Cutter 300 mm / 12 Inch
| inc.VAT | Original price was: £1,254.00.£1,065.90Current price is: £1,065.90. |
|---|---|
| ex.VAT | £888.25 |
Save £188.10 (15%)
View in-store products:
The Stihl TS480i Petrol Disc Cutter is the first petrol disc cutter from the brand with electronically controlled fuel injection. By choosing this cut off saw, you can be sure that it will not lack power or running qualities when cutting through hard material.
- Fuel injection technology,
- 300mm / 12 inch cutting blade,
- Can use it with a variety of cutting wheels,
- Ideal for cutting through brick, ceramic, concrete and steel.
- Can operate by hand or the FW 20 cart.
Ready when you are, the Stihl TS480i promises high cutting performance.
If your business requires a high-quality disc cutter that produces powerful torque and runs flawlessly and smoothly – then the TS 480i is a perfect choice.
Since its introduction, the construction industry has confirmed this cut-off saw as the leading option, all thanks to its fuel injection technology. It doesn’t matter what demand this Stihl machine put through, whether that’s a concrete slab or asphalt, this petrol disc cutter will not fail to meet the task.
Additionally, although a 72.2cc petrol engine powers it, the electronically controlled fuel/air mixture also reduces fuel consumption by 20% compared to standard petrol models. This 2-stroke models engine design, with its emission-reducing technology, also produces less carbon. Combining the two fuel-saving systems also helps the TS480i be lighter in weight and deliver more power.
Easy to use and operate.
A vital feature of all Stihl products is their user-friendliness. This TS480i disc cutter certainly fits that mould. As with most Stihl petrol machines, this model features the famous ElastoStart system, making it easier to start by reducing compression shocks.
What’s more, this Stihl cut off saw has an anti-vibration system, reducing the damage caused by the machines shaking to the hands and arms over long-term use.
Another fantastic Stihl design is the loop handle which makes the TS 480 i easy to manoeuvre and control the cut with total comfort at an optimum working position.
Weighing around 10 kilograms, it’s lightweight too, so you can move this Stihl cut off saw around with ease.
Built to last and continue performing.
Stihl only uses the best components to keep your TS 480 i in a serviceable condition for years to come. For example, the air filter is of a long life design with pre-separation quality. This filtration system ensures only the cleanest of air is goes into the ignition chambers whilst removing dirt and debris.
Moreover, the drive belt tensioning is semi-automatic, consistently re-tensioning the belt to increase the service life of shaft bearing and the belt itself.
Even the cutting wheel’s guard is of rugged magnesium, further increasing the life and reducing weight. In fact, the TS 480i’s guard and water attachment design are very well suited for the working environment.
Plenty of attachments to get the cutting job done efficiently
Should you need support for your TS480i disc cutter, a mobile frame to fit this cut off saw is available – the FW 20 cart. This support frame provides precise edges over long cuts, and with depths accurate to the millimetre, the FW 20 cart is specific enables the professional to improve their efficiency.
Additionally, there is a purposeful water delivery system, Again, electronically controlled via simplistic buttons. The flow of water is synced to the disc cutter’s engine speed to reduce user input. Should you need to intervene, there are plus/minus buttons to adjust the water volume, ensuring complete control over dust suppression.
Getting the correct saw blade for the TS480i is not an issue; although supplied with an abrasive cutting wheel, you can buy a range of Stihl manufactured composite resin or diamond cutting wheels for the job at hand.
– Download PDF Manual Here (If Available)
| Technical data | Value |
|---|---|
| CO2 g/kWh | 748 |
| Capacity cm3 | 72.2 |
| Performance kW | 3.9 |
| Vibration value, right m/s2 1) | 2.2 |
| Weight 2) | 10.01 |
| Sound pressure level dB(A) 3) | 98 |
| Sound power level dB(A) 3) | 112 |
| Vibration value, left m/s2 1) | 2.2 |
| Tank volume l | 0.72 |
| Power output kW/bhp | 3.9/5.3 |
| Weight kg 4) | 10 |
| Sound pressure level dB(A) 5) | 98.0 |
| Sound power level dB(A) 5) | 112.0 |
| Vibration levels left/right m/s² 6) | 2.2/2.2 |
| Cutting wheel mm/in | 300 / 12 |
| EPA Certified fuel consumption l/h | 2.11 |
1) K-factor according to DIR 2006/42/EC = 2m / s ²
2) Complete, without tools
3) K-factor according to DIR 2006/42/EC = 2.5 dB (A)
4) Without cutting wheel
5) Power factor according to DIR2006/42/EC=2.5(dB(A))
6) (K) factor according to Dir. 2006/42/EC = 2m/s²
| Power Type | |
|---|---|
| Machine Type | |
| Group | |
| User Type | |
| Brand | |
| Cutting Wheel Size | |
| CO2 Emissions | 748 g/kWh |
| Displacement | 72.2 cm³ |
| Performance | 3.9 kw |
| Tank Capacity | 0.72 L |
| Weight | 10.0 kg |
| Fuel Consumption | 2.11 l/h |
